Logcabin

Dimensions

Properties

Ends of the boards: straigth
Treatment of timber: Pressure-impregnated class 3: protection against rot, mould and insects. With additional wax additive for temporary and limited water-repellency.
Walls: traditional log cabin style construction in 28 mm thick spruce from the high North
Roof: steel roof with anti-fog cloth in roof tile shape

Dimension on ground baseproduct: 415 x 295 cm
Surface on ground baseproduct: 12,24 m²
Dimension inner baseproduct: 389,4 x 269,4 cm
Surface inner baseproduct: 10,49 m²
Dimension overall baseproduct: 435 x 311 cm
Surface overall baseproduct: 13,53 m²
Overhang roof front: 10 cm
Minimal recommended size of concrete base: 415 x 295 cm

Height of sidewall: 187 cm
Height of ridge: 248 cm
Roof slope: 19 °
m² to be treated: 115 m²
Weight: 700 kg
Packing WxDxH: 415 x 110 x 55 cm

Doortype 1: DDC01
Description door 1: double door Classic surface mounted
Glazing door 1: transparent glass 4 mm
Lock door 1: stainless steel latch with cylinder
Dimensions door 1 W x H: 145 x 189 cm
Daylight size door 1 W x H: 143 x 188 cm
Window type 1: EOR01L
Description window 1: single opening window standing type 1
Glazing window 1: transparent glass 4 mm
Daylight size window 1: 60 x 73 cm
