Dimensions

Properties

Type of construction: solid construction built with treated wood
Treatment of timber: class 3: against rot and insects, timber for outside use but without direct groundcontact
Roof: solid roof structure covered with 15mm thick spruce from the high North
Roof cover: black shingles
Warranty: 5 years, see warranty conditions

Dimension on ground carport: 352 x 538 cm
Dimension inner carport: 290 x 569 cm
Surface inner carport: 16,5 m²
Dimension overall carport: 350 x 569 cm
Surface overall carport: 19,92 m²
Minimal recommended size of concrete base: 352 x 538 cm

Free Height : 225 cm
Total height: 315 cm
Roof slope: 25 °
Weight: 384 kg
Packing WxDxH: 300 x 120 x 65 cm

Section of posts: 12 x 12 cm, to be anchored above ground. Anchors not included
