Logcabin

Dimensions

Properties

Ends of the boards: diamond
Walls: traditional log cabin style construction in 28 mm thick spruce from the high North
Roof: 15 mm thick spruce from the high North
Roof cover: green roofing

Dimension on ground baseproduct: 295 x 295 cm
Surface on ground baseproduct: 8,70 m²
Dimension inner baseproduct: 269,4 x 269,4 cm
Surface inner baseproduct: 7,26 m²
Dimension overall baseproduct: 315 x 301 cm
Surface overall baseproduct: 9,48 m²
Minimal recommended size of concrete base: 295 x 295 cm

Height of sidewall: 187 cm
Height of ridge: 235 cm
Roof slope: 19 °
m² to be treated: 85 m²
Weight: 575 kg
Packing WxDxH: 300 x 110 x 55 cm

Doortype 1: EDC01
Description door 1: single door Classic surface mounted
Glazing door 1: transparent glass 4 mm
Lock door 1: stainless steel latch with cylinder
Dimensions door 1 W x H: 88 x 189 cm
Daylight size door 1 W x H: 86 x 188 cm
Window type 1: EOR01L
Description window 1: single opening window lying type 1
Glazing window 1: transparent glass 4 mm
Daylight size window 1: 73 x 60 cm
