Corner Profile

Dimensions

Properties

Type of construction: garden shed with windproof timber corner joint
Walls: construction in 28 mm thick spruce from the high North
Roof: 15 mm thick spruce from the high North
Roof cover: green roofing

Dimension on ground baseproduct: 360 x 180 cm
Surface on ground baseproduct: 6,48 m²
Dimension inner baseproduct: 354,4 x 174,4 cm
Surface inner baseproduct: 6,18 m²
Dimension overall baseproduct: 366 x 211 cm
Surface overall baseproduct: 7,72 m²
Minimal recommended size of concrete base: 360 x 180 cm

Height of sidewall: 228 / 201 cm
Height of ridge: 238 cm
Roof slope: 9 °
m² to be treated: 80 m²
Packing WxDxH: 360 x 110 x 60 cm

Doortype 1: DDE01
Description door 1: double door Edge
Lock door 1: stainless steel ball latch with cylinder
Dimensions door 1 W x H: 120 x 184 cm
Daylight size door 1 W x H: 118 x 184 cm
